CAD Services

Our CAD Centre provides our customers and engineers with the ability to create 3D drawings for any part, whether that’s an existing one or a prototype. Drawings can then be sent to any of our CNC machines for automatic upload, ensuring absolute accuracy. Where appropriate we can also suggest amends to a design that will improve functionality and efficiency whilst often reducing ongoing maintenance and the associated costs.

Our Capabilities


SolidWorks and AutoCad

Conceptual design

Develop concepts into complete drawings and proposals

Design services

Individual components, new equipment and machinery, redesign of existing components

Manufacturing drawings

Provide complete manufacturing drawings
